Chevrolet Traverse gen 2 2018–present Transmission Reliability Under Real Ownership

Overview

Gen 2 Traverse (2018–2023) runs one basic playbook: a transverse 9-speed, front-drive layout, and if you spring for AWD you’re really buying extra driveline parts that can make extra noises. Simple. Until it isn’t.

I’ve been under a lot of these. On lifts, on cold mornings, on 100°F (38°C) days when the customer swears the “tranny is slipping” and what I actually find is an AWD module throwing a fit, or an axle interface clicking like a cheap ratchet. The platform itself isn’t a ticking time bomb, but it can absolutely nickel-and-dime you if you ignore the early tells.

You want the regulatory stuff up front? Good. NHTSA Safety Recall 20V668 (GM N202313440) is the one you do not blow off. Some 2018–2020 vehicles with the start-stop transmission accumulator were built with missing bolts on the accumulator endcap. Missing bolts can lead to a transmission fluid leak, loss of propulsion, and a fire risk if that fluid finds something hot enough to light it off. The fix is simple on paper: dealer inspects the accumulator endcap bolts, replaces the accumulator assembly if bolts are missing. No charge. VIN-based eligibility check through the official NHTSA VIN lookup or GM’s VIN-based recall status tool. Do that before you buy. Do it before you road-trip. Just do it.

This article stays locked on transmission and driveline. Gen 2 only. 2024+ is a different animal and outside scope.

Which Transmissions It Uses

Transmission Code	Gear Count	Drive Layout	Engine Pairing	Model Years (Gen 2)	Notes
9T65 (RPO M3V)	9	FWD	3.6L V6 (LGX)	2018–2023	Only verified transmission family used on this generation in U.S.-market service literature.
9T65 (RPO M3V)	9	AWD	3.6L V6 (LGX)	2018–2023	AWD adds PTU, prop shaft, and rear drive module; transmission remains 9T65.
9T65 (RPO M3W)	9	Platform-associated	3.6L V6 (LGX)	2018–2023	RPO M3W is referenced in GM service literature for 9T65 on this platform family; field identification should be confirmed by RPO label or scan tool build data.

No verified alternative transmissions were used in this generation of the Traverse. If someone tells you “the 8-speed is better” on a Gen 2 Traverse, they’re mixing platforms or making stuff up.

Main Failure Patterns

1) Start-stop accumulator bolts missing, fluid leak risk (Recall 20V668 / GM N202313440)

This is the big one. Safety recall. Real consequences.

Missing bolts on the start-stop transmission accumulator endcap. That’s the defect. If the bolts aren’t there, fluid can leak. If fluid leaks long enough, you get pressure problems, shift problems, then you’re dead in the water. Loss of propulsion. And if the fluid hits something hot, yeah, you’ve got fire risk. Messy.

• Failure mechanism: missing bolts on the accumulator endcap allows a transmission fluid leak.
• Owner risk: fluid loss can progress to loss of propulsion; leaked fluid can increase fire risk if it contacts an ignition source.
• Dealer remedy: inspect the accumulator bolts; replace the accumulator assembly if bolts are missing (recall repair is no-charge).
• VIN verification: official NHTSA recall VIN lookup or GM VIN-based recall status tool.

I’ve seen owners chase “rough shifting” with tune-up nonsense while the real problem was fluid level drifting down. Don’t be that person. Verify the recall. Then look for leaks anyway. Recalls don’t stop gravity.

2) Low-speed shift shudder, feels like the tranny is “hunting” (TSB 18-NA-091)

This one drives people nuts. Because it feels like the transmission is about to grenade, and most of the time it isn’t. It’s the torque converter clutch (TCC) doing a shaky re-apply right after a shift.

Symptom is pretty consistent: slight shudder during a shift at or below 40 Miles (64 km/h), light throttle, steady neighborhood cruising. You’ll hear “it’s slipping.” You’ll hear “it’s the motor mounts.” You’ll hear “it’s the tires.” Nope. Most of the time it’s TCC behavior plus fluid condition plus calibration.

• Symptom profile: brief shudder/vibration during a shift transition at or below 40 Miles (64 km/h) under light throttle.
• Verified service direction: confirm TCC shudder while monitoring TCC slip; update TCM calibrations; perform Service Fast Learn; drain and refill with DEXRON-VI; then drive at least 200 Miles (322 km) to validate.
• Why it matters: if it’s ignored and the fluid stays cooked/dirty, the converter clutch can start wearing in a way software can’t “band-aid” forever.

In my experience, when a shop says “they all do that,” what they mean is “I don’t want to diagnose it.” Sometimes it’s just calibration and fluid. Sometimes it’s already chewed up. Scan data tells the truth. A road test alone lies.

3) AWD moan/whine, clunk on the move, and everybody blames the transmission (TSB 18-NA-105)

AWD Traverse adds a PTU and a rear drive module with a clutch system. More parts. More opportunities to make weird noises. That’s the trade.

TSB 18-NA-105 talks about a whining/moaning noise throughout the vehicle and/or a clunk when shifting into AWD while driving at a steady speed. GM’s guidance points to excessive load on the driveline between the PTU and the rear differential and calls for reprogramming the rear differential clutch control module to the latest calibration. And the bulletin excludes vehicles with a G99 differential.

• What it feels like: noise that seems like it’s coming from everywhere, and a clunk when AWD engages while you’re rolling.
• What it really is: AWD load management acting up, not the 9T65 “lunching gears.”
• Repair direction: rear differential clutch control module programming update (excludes G99 differential).

I’ve had customers swear the tranny was dying because the noise lined up with shifts. Makes sense from the driver seat. Underneath? Different story.

4) Early-build rear differential lubrication loss, torque tube contamination, rear end gets angry (TSB 18-NA-311)

This is a real mechanical failure pattern. Not feelings. Not “driver perception.” Actual oil where it shouldn’t be.

TSB 18-NA-311 lays it out: a mis-machined chamfer on the rear diff pinion can let the pinion seal roll and not seat right. Then gear oil leaks into the torque tube, the differential loses lubrication, and you get rear grinding/howling/whining and vibration. AWD vehicles. Build-date sensitive. If you’re outside the build window, you diagnose like normal. If you’re inside it, you take it seriously.

• Symptom profile: rear grinding, howling/whining, vibration on AWD.
• Trigger: build dates defined by GM in the bulletin.
• Repair direction: check build date; check rear diff fluid level; remove torque tube and inspect for pinion seal oil leak; replace rear axle differential carrier if leak is confirmed.

I’ve pulled torque tubes on stuff like this and found oil migration that’s just ridiculous. The driver hears “rear howl.” The shop sells tires. The diff keeps running low. Then it grenades. That’s how it goes when nobody checks the obvious.

5) Front click on accel/decel, cheap little hardware problem that can snowball (TSB 17-NA-143)

Clicking from the front on low-speed acceleration and deceleration. Wheels mostly straight. Customers hate it. They also assume the tranny is doing something weird. It’s not.

GM service literature addresses the axle/hub interface and loss of torque on the drive axle nut. The repair path is to replace the axle nut and washer and follow the specified procedure. It’s small money early, bigger money later if someone keeps driving it and beats up the interface.

• Symptom profile: clicking noise from the front during accel/decel at low speeds.
• Service direction: replace axle nut and washer, torque per procedure.
• Why it matters: ignored long enough, you can end up chasing hub/axle spline issues that didn’t need to exist.

6) Rear differential clutch module corrosion, AWD warnings, and scan data saves your sanity (TSB 18-NA-007)

This is one of those failures that looks like ten different things depending on who’s driving and what the weather’s doing. GM guidance documents corrosion at the seam and connector area of the rear differential clutch module. Corrosion can lead to communication faults, AWD warning messages, drivability complaints. People call it “slipping.” It’s not always slipping. Sometimes it’s electronics having a bad day.

• Symptom profile: Service AWD messages, communication DTCs, intermittent AWD function.
• Failure mechanism: corrosion at the module housing seam/connector area.
• Repair direction: inspect for corrosion and replace the module if corrosion is present; inspect wiring/connector condition as needed.

In my experience, if a shop starts throwing parts at the PTU or rear diff without pulling codes and checking module comms, you’re about to pay for somebody’s guesswork. Scan-first. Always.

7) Left axle not fully seated, then the whole thing acts like it ate itself (GM service guidance, 2023 bulletin)

This one shows up after repairs. A lot.

GM service guidance documents that if the left axle isn’t fully seated in the transmission, you can get grinding, slipping, or no movement in drive or reverse. That’s usually a service-induced mess. The worst part? If it’s driven while partially engaged, it can damage the differential interface hard parts. Then you’re not just “reseating an axle.” You’re pulling the tranny. You’re paying real money.

• Symptom profile: grinding/slip/no-move, often right after axle/suspension work.
• Failure mechanism: incomplete axle spline engagement at the transmission/front differential interface.
• Consequence: a simple seating issue can turn into teardown-level repair if driven.

Typical Repair Costs

Repair	When it shows up	Parts (USD)	Labor (USD)	Total (USD)	Basis
Recall 20V668 inspection/repair (accumulator bolts)	Any time; VIN-eligibility based	$0	$0	$0	OEM recall remedy (no-charge)
TCM software update + Service Fast Learn + drain/refill (TCC shudder bulletin path)	Shudder at or below 40 Miles (64 km/h)	$120–$280	$180–$450	$300–$730	Service Bay Benchmark
Torque converter replacement (when shudder persists after software/fluid)	Persistent shudder, repeat visits	$650–$1,150	$900–$1,700	$1,550–$2,850	Service Bay Benchmark
Rear differential clutch control module reprogram (AWD load noise)	Whine/moan or clunk on AWD engagement	$0–$60	$150–$350	$150–$410	Service Bay Benchmark
Rear differential clutch module replacement (corrosion-related)	Service AWD messages, comm faults	$450–$900	$250–$650	$700–$1,550	Service Bay Benchmark
Rear differential carrier assembly replacement (build-range pinion seal oil migration case)	Rear howl/grind/vibration; bulletin build date match	$1,100–$2,100	$600–$1,200	$1,700–$3,300	Service Bay Benchmark
PTU replacement (AWD only, when leakage or internal wear is confirmed)	AWD-specific leak/noise; confirmed by inspection	$900–$1,800	$500–$1,100	$1,400–$2,900	Service Bay Benchmark
Axle nut/washer correction for front click	Click on tip-in/tip-out at low speed	$20–$80	$120–$250	$140–$330	Service Bay Benchmark
Internal transmission repair or replacement (9T65)	Loss of drive, repeated harsh shift faults, internal damage confirmed	$3,500–$6,000	$1,300–$2,700	$4,800–$8,700	Service Bay Benchmark

Prices swing a lot by region. Big cities hurt. Rural areas can be cheaper, or they can be worse because nobody wants to touch a modern 9-speed. And if somebody misdiagnoses an AWD issue as a “bad tranny,” you’ll pay twice. I’ve watched it happen.

Best and Worst Years

Model Year (Gen 2)	Drivetrain	Risk Level	Dominant Drivetrain Concerns	Why
2018	FWD / AWD	Medium	TCC shudder bulletin activity; AWD load/noise calibration; rear differential carrier bulletin is build-range sensitive	First-year rollout is where calibration and early-build mechanical issues cluster in service literature.
2019	FWD / AWD	Medium	TCC shudder bulletin activity; AWD module corrosion bulletin applies by environment; recall population overlaps 2018–2020	Lots of these are fine if the fixes were handled and the fluid wasn’t neglected.
2020	FWD / AWD	Medium	Recall 20V668 applies to the model-year range; normal wear patterns otherwise	Recall exposure stays the big must-check. After that, it’s maintenance and diagnosis quality.
2021	FWD / AWD	Medium-Low	Shudder complaints still possible; module corrosion depends on climate; axle/hub interface noises	Early-build mechanical bulletins are less dominant as production matures.
2022–2023	FWD / AWD	Medium-Low	Mostly wear-and-service outcomes; service-induced axle seating issues can create major symptoms after repairs	It’s less about factory defects, more about how it was serviced and who touched it.

Warning Signs & Early Detection

You want the cheapest version of owning one of these? Catch the dumb stuff early. Don’t drive it until it’s screaming.

Shudder. Moan. Clunk. Click. Leak. Those five words cover most of the real drivetrain stories I see on this platform. The trick is tying the sound to the right chunk of hardware. And yeah, that takes scan data and a tech who isn’t guessing.

Red Flag	What it feels like	Most likely area	First check in a shop	Why it matters
Shudder during a low-speed shift at or below 40 Miles (64 km/h)	Brief vibration during shift transition	TCC behavior / fluid condition / TCM calibration	Road test with scan data for TCC slip; check fluid condition and service history	Early correction is often software + fluid; ignored long-term can turn into torque converter replacement.
Whine/moan through the vehicle, plus clunk when AWD engages while moving	Noise changes with AWD engagement	AWD control calibration or load management	Check for applicable rear diff clutch control module updates; inspect driveline	Some cases are calibration fixes; others reveal PTU or rear module problems.
Rear howling/grinding or vibration on AWD	Rear-end noise that rises with speed	Rear differential lubrication and torque tube contamination	Check rear diff fluid level/condition; inspect torque tube for oil migration	Low lubrication can chew ring-and-pinion surfaces fast.
Front click on tip-in/tip-out at low speed	Single or repeating click on accel/decel	Axle/hub interface hardware	Verify axle nut/washer condition and correct torque procedure	Cheap early; can become messy spline/hub interface damage later.
Service AWD message or AWD-related DTCs	Intermittent AWD function or warnings	Rear differential clutch module / wiring	Full scan for comm faults; corrosion inspection at module seam/connector	Scan-first prevents the classic “throw a PTU at it” mistake.
Grinding/slipping/no movement right after axle or suspension work	Immediate drivability loss after repair	Left axle seating at transmission interface	Confirm axle fully seated and retention features intact before driving	A short drive can turn it into teardown-level damage.

When to Walk Away

I don’t tell people to walk away lightly. Cars break. People fix them. Fine. But some situations are just bad math.

Walk-away scenario	Why it’s a problem	What it usually turns into	Practical risk
Unverified completion of Recall 20V668 / GM N202313440	Fluid leak risk with loss of propulsion potential	Unknown prior fluid-loss exposure, unknown internal wear	Safety exposure plus unknown transmission health history
Shudder plus nasty fluid plus a history of “normal, don’t worry”	Suggests long-term operation with degraded fluid and TCC distress	Torque converter replacement, then maybe deeper internal work	High likelihood of spending soon
Rear howl/vibration on AWD with evidence of oil migration	Lubrication problem, possible hard-part wear	Rear differential carrier replacement	Repair cost can erase any “good deal” discount
Multiple driveline noises plus AWD warnings	Layered electrical + mechanical problems	Stacked diagnostics and stacked repairs	Budget gets wrecked fast
Fresh axle/suspension work followed by grinding/no-move	Axle seating error and immediate damage risk	Transmission removal and hard-part repair if driven	One bad test drive can turn it into a major job

Ownership Reality

This is where people get mad. Because the owner’s manual vibe is “it’s fine.” Real life is “service it like you mean it.”

I’ve seen dozens of “lifetime fluid” drivetrains come in with shavings, burnt smell, and a customer who did everything “right” because they followed the bare minimum schedule. Lifetime fluid is a joke in heavy traffic, heat, towing, short trips, mountains. That’s most of the U.S. driving map right there.

Topic	OEM Guidance (maintenance schedule language)	Real-world outcomes I see	Cost consequence if ignored
Transmission fluid service	Normal schedule does not list routine ATF change; severe schedule calls for ATF change at 45,000 Miles (72,000 km) and then at the same interval progression	Vehicles used in traffic/heat/towing behave like severe use even when owners think they’re normal	Higher odds of shudder complaints; converter jobs become more common on neglected units
AWD driveline behavior	Software updates are condition-based; module replacement is condition-based	Calibration and module health drive a lot of symptoms; corrosion environments accelerate module failures	Misdiagnosis leads to wasted parts and wasted money
Noise vs failure	Service literature separates noise paths: calibration, hardware interface, mechanical wear	A click can be axle/hub hardware; a rear howl can be lubrication-related; both get mislabeled as “bad tranny”	Small jobs become big jobs when ignored
Warranty timing	Factory coverage ends before some patterns mature for second owners	Plenty of these show up right as they transition out of basic coverage	Owner carries full cost of module/PTU/converter work
Maintenance myths	No dipstick means service is controlled, not optional	Skipping service because it’s “sealed” is a common reason I see repeat shudder complaints	Deferred service turns into parts replaced

And one more thing: a lot of “transmission” diagnoses are really driveline diagnoses. PTU loads, rear module behavior, axle interfaces. If the shop isn’t looking at the whole chain, you’re going to pay for a band-aid fix slapped on the wrong end.

Lawsuits, Complaints & Regulatory History

For Gen 2 Traverse transmission and driveline, the clear regulatory event is NHTSA Safety Recall 20V668 / GM N202313440 for the start-stop transmission accumulator bolts. That’s a real defect, it’s documented, and it has a defined remedy.

Outside of that recall, the pattern is service-bulletin driven. It’s less “massive lawsuit material” and more “known issues with known fixes” if you catch them early and the diagnosis isn’t sloppy.

• TSB 18-NA-091: low-speed shudder tied to TCC re-apply; confirm with scan data; calibrations + Service Fast Learn + DEXRON-VI drain/refill; validate with 200 Miles (322 km) of driving.
• TSB 18-NA-105: AWD whine/moan and/or clunk during AWD engagement; reprogram rear differential clutch control module; excludes G99 differential.
• TSB 18-NA-311: rear differential lubrication loss mechanism tied to pinion seal seating and torque tube oil migration on a defined build-date range; replace differential carrier when leak is confirmed.
• TSB 18-NA-007: rear differential clutch module corrosion and communication faults leading to AWD warnings and drivability issues.
• TSB 17-NA-143: front clicking noise on accel/decel at low speed related to axle/hub interface hardware procedure.

If you want a clean ownership file, your process is boring: verify the VIN for recall status, then make sure any real symptom gets a scan-backed diagnosis, not vibes. I’m saying that because I’ve watched customers spend $2,000 chasing the wrong end of a noise.

Bottom Line

Gen 2 Traverse (2018–2023) runs the 9T65. That’s it. The transmission itself doesn’t have a reputation for randomly lunching gears every Tuesday. The platform’s pain points are more annoying than dramatic: shudder behavior tied to TCC control and fluid condition, AWD load/noise behavior that needs programming, rear diff lubrication issues on a defined early build range, module corrosion that needs scan-first diagnosis, and service-induced axle seating errors that can turn into a monster if somebody keeps driving it.

Do the recall check. Always. If Recall 20V668 / GM N202313440 isn’t documented as complete for that VIN, the deal is already contaminated.

Then drive it like you’re trying to make it misbehave: low-speed light throttle for shudder, steady-speed AWD engagement for clunk/noise, listen for rear howl, feel for front click. If it’s quiet and clean, and the service history doesn’t look like a mystery novel, these can be decent family haulers. If it’s already throwing hints and the seller’s story is thin, you’re buying someone else’s problem.
